LL Magazine PCB Loader Machine 1785*860*1250 For SMT Reflow Soldering

Product Categories
UNIQUE AUTOMATION LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

LL Magazine PCB Loader Machine 1785*860*1250 For SMT Reflow Soldering

  • 1
  • 2

Brand Name : UA

Model Number : LD-3-390

Certification : CE

Place of Origin : CHINA

MOQ : 1 unit

Price : Negotiable

Payment Terms : T/T

Supply Ability : 50 units per month

Delivery Time : 7 days

Packaging Details : vacuum packing for sea transportation

Magazine model : LL

Magazine size (mm) : 535*460*565

Machine Dimension (mm) : 1785*860*1250

PCB Dimension (mm) : 50*50-520*390

Power supply : AC 220V 50/60 Hz

Compressed air : 4-6 Kg/cm²

Control mode : PLC + touch panel screen

Power : 100 W

Contact Now

PCB Loader Unloader

PCB magazine loader for SMT reflow soldering

Description

This unit is used for loading PCBs

it is very easy operating, can save the labor and improve the accuracy.

Features

1. Touch screen controlled component,easy to operate and convenient man-machine interaction.
2. Multiple sound and light alarming functions
3. Pneumatic PCB clamping structure
4. Lifting distance adjustable according to PCB, 4 kinds of distance(10mm, 20mm, 30mm and 40mm)
5. Loader configured with inner push board component, save the cost of buying PCB moving machine independently.
6. Optional SMEMA port for communication between machines.

Specifications

Size LL
Model LD-3-390
Machine Dimension 1785*860*1250 mm
PCB Dimension 50*50-520*390 mm
Mgazine Size 535*460*565 mm
Weight 240 KG

Package and Shippment

Package

Packing way: internal vacuum packing and outer wooden packing.

Shipping

1. By air. International Express like Federal Express, DHL, UPS, TNT, etc.

( Fast transportation, safe and accurate)

2. By sea. Suitable for the transportation of large items, carrying a lot of goods and cheap.

3. Other method as you customized.
